| Model | LC-001 | |||
| Standard Variable Frequency Drive Models | Rated Input Voltage (V) | Rated Output Power (kW) | Input Current (A) | Rated Output Current (A) |
| JHI - 70 - 0D75G - 1 | Single-phase 220V | 0.75KW | 8.2 | 4 |
| JHI - 70 - 1D5G - 1 | Single-phase 220V | 1.5KW | 14 | 7 |
| JHI - 70 - 2D2G - 1 | Single-phase 220V | 2.2KW | 23 | 9.6 |
| JHI - 70 - 4D0G - 1 | Single-phase 220V | 4KW | 20 | 17 |
| JHI - 70 - 0D75G - 4 | Three-phase 380V | 0.75KW | 3.4 | 2.1 |
| JHI - 70 - 1D5G - 4 | Three-phase 380V | 1.5KW | 5 | 3.8 |
| JHI - 70 - 2D2G - 4 | Three-phase 380V | 2.2KW | 5.8 | 5.1 |
| JHI - 70 - 4D0G - 4 | Three-phase 380V | 4.0KW/5.5KW | 10.5 | 9 |
| JHI - 70 - 5D5G - 4 | Three-phase 380V | 5.5KW/7.5KW | 14.5 | 13 |
| JHI - 70 - 7D5G - 4 | Three-phase 380V | 7.5KW/11KW | 20 | 17 |
| Single-phase 220V | 0.75 kW - 220V |
| 1.1 kW - 220V | |
| 1.5 kW - 220V | |
| 2.2 kW - 220V | |
| 4 kW - 220V | |
| Three-phase 380V | 0.75 kW 380V |
| 1.5 kW 380V | |
| 2.2 kW 380V | |
| 3 kW 380V | |
| 7.5 kW 380V | |
| 4 kW 380V | |
| 5.5 kW 380V |
Quality Guarantee
Compact and Elegant
Affordable Price
